Synthetic Rubber Open Mixing Mill Machine 50HRC 60HRC With Dual Output Reducer

Name: Synthetic Rubber Open Mixing Mill Machine 50HRC 60HRC With Dual Output Reducer
Brand: honghesheng
Price: 25000 USD

Wholesale Synthetic Rubber Open Mixing Mill Machine 50HRC 60HRC With Dual Output Reducer from china suppliers

Brand Name : honghesheng

Model Number : XK450

Certification : CE

Place of Origin : CHINA

MOQ : 1 SET

Price : USD25000-6000/SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200SETS/MONTH

Packaging Details : wood package /20/40GP/HC

After-sales service provided : Engineers available to service machinery overseas,Field installation,commissioning and training,Video technical support

Type : Open Mixing Mill

Roller hardness : 50~60HRC

Bush : nylon bush,bearing bush,ball bearing Bush

Voltage : 380V,Customer's Request,380V/50HZ,220/380V,AC380V

Power(w) : 37kw,4.5KW,20KW,5KW for lab two roll mill

Weight : 5200kgs,1000kg,2T

Dimension(l*w*h) : 1100*700*1200mm,1226x830x1295mm,1*1.1*1.4(M),1100*650*1500,1160*920 *1370mm

Warranty : 1 Year

Condition : New

Contact Now

Rubber mixing mill machine / open mixing machine / rubber mixing machine

Introduction of open mixing mill

Open mixing mill is extensively used in rubber products manufacturing factory to get best mixing dispersion of ingredients and raw rubber. Coupled with stock blender, these mills saves labor and increase productivity.

Open mixing mill is used for mixing and kneading raw rubber, synthetic rubber, thermoplastics or E.V.A.with chemicals into even materials. The even materials can be fed to calender, hot presses or other processingmachiner3t for making rubber or plastic products.

It adopts dual output reducer, the front and behind roller can be driven separately with rolling bearing structure, the roller can adopts hollow center groove roller or drilling hole smooth roller against difference using scope as mixing, refining or press pieces etc.

Parameter of open mixing mill

Synthetic Rubber Open Mixing Mill Machine 50HRC 60HRC With Dual Output Reducer

Technical parameters:

Version	XK-160	XK-250	XK-300	XK-400	XK-450	XK-560	XK-660
Roll diameter(mm)	160	250	300	400	450	560	660
Working length of rolls(mm)	320	620	750	1000	1200	1530	2130
Front roll surface speed(m/min)	8.99	15.3	15.1	18.65	24.32	27.72	28.6
Friction ratio	1:1.35	1:1.1	1:1.27	1:1.27	1:1.27	1:1.2	1:1.24
Max.nip (mm)	4	8	8	10	15	15	15
Capacity per.batch (kg)	1-2	10-15	15-20	18-35	25-50	35-50	165
Motor power (kw)	5.5	18.5	22	37	55	90	245
Overall dimensions(mm)	1160920 1370	31201322 1500	35801550 1695	43501850 1780	56702390 1670	58452284 1978	74653662 2080
Weight(kg)	1000	4000	5200	7600	12000	23000	49000
